Ceramic Filter Press

What is Ceramic Filter Press?

Ceramic filter Press is a new type, high efficiency, energy saving solid-liquid separation equipment, which can be divided into ceramic vacuum filter and ceramic disk filter. Ceramic filter Press mainly consists of ceramic filter plate, roller system, mixing system, feeding and discharging system, vacuum system, filtrate discharge system, scraping system, backwashing system, combined cleaning (ultrasonic cleaning, automatic acid cleaning) system, full-automatic control system, tank, frame and other parts.

Ceramic filter Press is mainly used for solid-liquid separation, which will retain the solid particles in the suspension on the surface of ceramic medium, while the liquid will flow out through the ceramic medium, thus realizing the purpose of solid-liquid separation.

If you are a beginner and do not know about Ceramic, tell us your raw material characteristics, finished product requirements, site conditions, production budget, hourly production, and other requirements, we have professional engineers to equip you with a suitable model at a reasonable price. Next, let’s see the types of Ceramic Filter Press we can supply.

What Is Ceramic Filter Press Used For?

Ceramic filter Press is widely used in dewatering treatment of non-ferrous metal mining, metallurgy, chemical industry, environmental protection, sewage treatment, food and other industries.

For example, in the mining industry, it can be used for filtering and dewatering of mine concentrates such as iron ore concentrate, zinc concentrate, sulfur concentrate, copper concentrate, nickel concentrate, molybdenum concentrate, lead concentrate, tungsten concentrate, manganese concentrate, vanadium concentrate, aluminum concentrate, gold concentrate, etc.;

In the metallurgical industry, it can be used for treating the slag, soot and so on;

In the chemical industry, it can be used for the oxides, electrolysis slag, leach slag, slag, filtering suspensions, catalysts, etc.;

In the field of environmental protection,It can be used for wastewater treatment, sludge dewatering and so on.

For example: A large foreign mining plant test phase, has been due to dewatering amount can not meet the requirements of the agonizing. Introduced by a friend, Chunlei technical personnel according to the customer’s terrain and the nature of the ore dressing plant ore, recommended for its ceramic vacuum filter. The vacuum filter is cheap, high efficiency, high output, low water content, energy saving in more than 85%, the filtrate water is clear and transparent can be recycled and reused, deeply customer favorite.

Ceramic Filter Press ordered by Customer

Chunlei Machinery has been engaged in mining machinery manufacturing for more than 30 years, with a wealth of experience in building websites and customer cases, served customers all over the world!

Technical Parameters of Ceramic Filter Press

Model number	Filter area/m2	Filter disc/ring	Number of filter plates/pieces	Tank volume/m3	Installed power/KW	Operating power/Kw	Host machine（L×W×H）/m
TC-1	1	1	12	0.21	3.5	2.0	1.6×1.4×1.5
TC-4	4	2	24	1.0	7.0	3.0	2.4×2.5×2.1
TC-6	6	2	24	1.2	7.0	6.0	2.4×2.9×2.5
TC-9	9	3	36	1.7	9.0	7.0	2.7×2.9×2.5
TC-12	12	4	48	2.2	11.0	7.5	3.0×2.9×2.5
TC-15	15	5	60	2.7	11.5	8.0	3.3×3.0×2.5
TC-21	21	7	84	4.0	13.5	9.0	4.6×3.0×2.6
TC-24	24	8	96	4.5	16.5	10.5	4.9×3.0×2.6
TC-27	27	9	108	5.0	17.0	11.0	5.2×3.0×2.6
TC-30	30	10	120	5.5	17.5	11.5	5.5×3.0×2.6
TC-36	36	12	144	7.0	23.0	16.0	6.6×3.0×2.6
TC-45	45	15	180	8.5	25.0	19.0	7.5×3.0×2.6
TC-60	60	15	180	12.5	33.0	22.0	7.5×3.3×3.0
TC-80	80	20	240	16.2	40.0	24.0	9.0×3.3×3.0
TC-102	102	17	204	18.5	53.0	35.0	8.8×3.6×3.3
TC-120	120	20	240	20	60.0	40.0	9.7×3.6×3.3
TC-150	150	25	300	24	75.0	47.0	11.2×3.6×3.3

Working Principle of Ceramic Filter Press

The working principle of the ceramic filter Press is mainly based on vacuum suction and capillary microporous action. Specifically, when the vacuum pump is activated, negative pressure is formed in the filtration chamber, under the action of negative pressure, the solid material in the slurry tank is adsorbed on the surface of the ceramic filter plate, forming a cake, while the liquid is due to the action of the vacuum pressure difference and the hydrophilicity of the ceramic filter plate, through the surface layer of ceramic filter plate into the inner cavity of the ceramic plate, and then through the pipeline to reach the discharge tank and then discharged, so as to achieve the purpose of solid-liquid separation. After that, the rotor drives the filter plate and the cake adsorbed on the plate to the drying area, where the cake continues to be dewatered under the action of vacuum. With the filtration process, solid particles in the ceramic filter plate surface to form a layer of cake, when the cake reaches a certain thickness, the need to stop filtering and ultrasonic with a low concentration of acid for joint cleaning to ensure that the ceramic plate for efficient use.

Advantageous features of Ceramic Filter Press

• High-precision, high-vacuum filtration: The microporous aperture of ceramic filter plate is very small, generally not larger than 2μm, which can effectively retain solid particles and obtain clear filtrate with low liquid content in the filter cake. The high vacuum degree of 0.09-0.098MPa can be achieved to provide strong suction force, which makes the solid-liquid separation more thorough, and also has good filtration effect for materials with fine particles.
• Energy saving and high efficiency: the capillary effect of the ceramic filter plate makes the filtration process not need to consume a lot of energy to form the filtration pressure difference, significant energy saving and large processing capacity.
• High degree of automation: the use of PLC, microcomputer combined with automatic valve control can realize automatic feeding, automatic cleaning, automatic unloading and other operations, reducing labor intensity, reducing the error and uncertainty of manual operation.
• Strong corrosion resistance: ceramic materials have excellent corrosion resistance, can adapt to a variety of harsh working environments, prolonging the service life of the equipment.
• Strong applicability: It has strong adaptability to the filtering medium and can adapt to materials of different properties, including materials of various fineness and materials that need washing.
• Small footprint: ceramic filter Press has a compact structure, small footprint, and is easy to install and move.

What can ChunLei do for you-about service？

Ceramic Filter Press price

As for the price, we can’t show you the exact price because we deal with customers from all over the world and there are many factors affecting the price. If you want to know the price of Ceramic Filter Press, you can leave a message to us on this page, we have professional sales staff and engineers to explain to you.

As one of the old brand mining machinery manufacturers in Henan, Chunlei Machinery strictly controls every Ceramic Filter Press for sale with more reliable quality. Chunlei has its own R&D team and production site, and sells directly, enjoying factory super low price. What are you waiting for? Contact us immediately!
